Loc-N-Load™ Interlocking Plates – Metric

SKU:

$320.00$1,985.00

Fast-swap, interlocking Loc-N-Load™ metric CMM docking rails and fixture plates secure and release quickly for repeatable setups with the use of magnets. Interlocking CMM Fixture Plates – 13mm thick, M6 thread, 20 x 20mm hole pattern.

SKUNamePriceWeightDimensionsSelect Qty / Check Box
LNL-M180180Loc-N-Load™ Interlocking Plates - Metric - 180x180$320.004 lbs8 × 7 × 1 in
LNL-M180360Loc-N-Load™ Interlocking Plates - Metric - 180x360$525.006 lbs15 × 7 × 1 in
LNL-M360360Loc-N-Load™ Interlocking Plates - Metric - 360x360$870.0011 lbs15 × 14 × 1 in
LNL-M360540Loc-N-Load™ Interlocking Plates - Metric - 360x540$1,985.0018 lbs22 × 14 × 1 in
LNL-M360180Loc-N-Load™ Interlocking Plates - Metric - 360x180$525.006 lbs15 × 7 × 1 in

Fast-swap, interlocking Loc-N-Load™ metric CMM fixture plates secure and release quickly for repeatable setups with the use of magnets. The 20 x 20mm hole pattern seamlessly integrates and the plates are quickly assembled without tools. Once assembled, inspectors can program several small setups, multi-part fixtures, or add large parts that span multiple plates. The docking rail stays out of the probe’s travel to maximize the CMM’s work envelope.

13mm thick, M6 thread, 20 x 20mm hole pattern; available in various sizes with custom sizes available upon request.

To add to your order, see Docking Rails and Accessory Plates.

WeightN/A
DimensionsN/A
size

180×180, 180×360, 360×360, 360×540, 360×180
